ZK8208- 500/600/700/800 Double Head processing machine tool

The double-end centering machine is a special CNC machine tool mainly used for processing the end face and center hole of shaft parts. It can clamp once and complete milling, drilling, tapping, chamfering and other processes on both ends of the workpiece at the same time, improving processing efficiency and accuracy.
Multi-spindle centering machines can be divided into three types: flat bed, inclined bed and vertical according to the form of the bed. According to the number of spindles, it can be divided into single head, double head and multi-head.
Double-head centering machines are widely used in the processing of shaft parts in automobiles, motorcycles, motors, pump valves, agricultural machinery, construction machinery and other industries. For example, half shafts, cams, E-bolts, etc. can all be processed with a milling machine.
Both ends of the machine use milling spindles, drilling spindles, and threading spindles, which also have functions such as chamfering and end cylindrical turning. The same spindle can be used at both ends, or spindles with different functions can be deployed separately to process both ends of the workpiece simultaneously. Or perform the same or different processing in turns, which is a typical multi-functional spindle combination CNC machine tool.
